ReenVacu©
Product Range
ReenVacu © provides an extensive selection of vacuum glass products, each designed with distinct advantages and specifications to meet various needs. Below, we highlight the key differences among them.
ReenVacu©
ReenVacu© is the best among the best. The insulation value (U-value) of this vacuum glass is < 0.43 and the minimum glass thickness is only 8.2 mm. Due to the limited thickness, the insulation value and the low weight, ReenVacu© is very suitable for installation in existing frames. The glass not only insulates very well, there are also many combinations and compositions possible. Think of a combination of ReenVacu© Excellent with stained glass panels, triple glass, fire-retardant glass (30 or 60 minutes), sound-retardant glass and there are many more possibilities.
Due to the perfect specifications of this ReenVacu©, the glass is also extremely suitable for installation in monumental buildings. ReenVacu© is also very suitable for installation in your current frames, to replace your double glazing.
Specifications
0.43 U-value
6-16 mm Thickness
78% LTA
46% ZTA
Vacuum Glass ReenVacu
ReenVacu© Excellent can be combined with several types of glass, including satin glass, figured glass, burglar-resistant glass, but also fire-resistant glazing of 30 or 60 minutes;
It is double-sided safety glass, injury-resistant and to prevent thermal breakage;
Benefits:
- The glass is available in many different models and can even be bent into different radii;
- ReenVacu© can also be combined with secondary glazing: both in wooden profile version and in aluminium with a choice of standard Ral colours;
- It is perfect for every situation like plastic windows, aluminum or even to upgrade your house to the newest generation and save money on your energy bill.
Technical Details:
- Thickness: 6-16 mm
- U value of 0.43
- Light Transmittance: Over 78% for clear panels
- ReenVacu© has a safety classification of 1C3
- We offer a 20-year warranty on ReenVacu© products.
ReenVacu Excellent©
ReenVacu Excellent© stands as the top-performing insulating glass panel available today. With thickness options ranging from 18.2 mm to 60 mm and an impressive U-value of 0.29, it delivers unmatched energy efficiency. Featuring a durable black plastic spacer and full tempering on both sides, safety is always a priority. Ideal for all applications, whether for plastic windows, aluminum frames, or modernizing your home to the latest standards.
ReenVacu Excellent© helps you save on energy costs while enhancing comfort and style.
Specifications
0.29 U-value
18-60 mm Thickness
76% LTA
41% ZTA
Benefits:
- ReenVacu Excellent© is the best isolating glass panel on the market
- It is always with black plastic spacer and both sides are full tempered! So always safety first.
- It is perfect for every situation like plastic windows, aluminum or even to upgrade your house to the newest generation and save money on your energy bill.
Technical Details:
- Thickness: Customizable from 18.2 mm to 60 mm thickness.
- U value of 0.29
- Light Transmittance: Over 76% for clear panels
ReenVacu Ultra Clear©
Ultra-clear vacuum glass is an advanced building material known for its exceptional transparency and insulation properties. It consists of two or more layers of glass separated by a vacuum, significantly reducing heat transfer and enhancing energy efficiency in constructions.
Specifications
0.45 U-value
8-12 mm Thickness
82% LTA
64% ZTA
Benefits:
- Superior thermal insulation, reducing energy costs
- Enhanced soundproofing for quieter interiors
- High durability and resistance to environmental stress
- Improved natural light transmission, maintaining clarity
Technical Details:
- Thickness: Varies depending on specific requirements, typically around 8-12 mm
- Thermal Conductivity: As low as 0.4 W/m²K
- Acoustic Performance: Can achieve up to 40 dB noise reduction
- Light Transmission: Up to 64% for optimal clarity
ReenVacu Laminated©
Vacuum Glass Laminated for Buildings
Vacuum glass laminated panels are an advanced solution for modern construction, offering enhanced insulation and durability. These panels consist of multiple layers of glass with a vacuum space in between, providing superior thermal performance and soundproofing.
Specifications
0.41 U-value
13.52-25.52 mm Thickness
77% LTA
44% ZTA
Benefits:
- Exceptional thermal insulation, reducing energy costs
- Superior soundproofing for a quieter indoor environment
- High durability and resistance to impact
- Improved safety with shatter-resistant properties
- Lightweight design for easier installation
Technical Details:
- Thickness: Customizable from 13.52mm to 25.52mm
- U-value: As low as 0.4 W/m²K
- Sound Insulation: Up to 42dB reduction
- Light Transmittance: Over 77% for clear panels
- Complies with international safety and energy efficiency standards
ReenVacu Fire Resistent©
Fire-resistant vacuum glass is an innovative solution designed to enhance the safety and energy efficiency of modern buildings. This type of glass integrates advanced technology to provide superior insulation and fire protection, meeting stringent safety standards while maintaining aesthetic appeal.
Specifications
0.43 U-value
21-60 mm Thickness
77% LTA
43% ZTA
Benefits:
- Enhanced Safety: Offers exceptional fire resistance, providing crucial time for evacuation during emergencies.
- Energy Efficiency: Superior thermal insulation reduces heating and cooling costs, contributing to sustainable building practices.
- Noise Reduction: Effective soundproofing capabilities create a quieter indoor environment.
- Durability: High resistance to thermal stress and impact increases the lifespan of the glass.
- Aesthetic Flexibility: Available in various styles and finishes to suit diverse architectural designs.
Technical Details:
- Thermal Conductivity: Extremely low thermal conductivity due to the vacuum space between glass panes.
- Fire Rating: Meets and exceeds industry standards for fire resistance, ensuring compliance with safety regulations.
- Glass Composition: Typically consists of two or more layers of tempered glass with a vacuum seal.
- Thickness: Varies depending on specific requirements, generally ranging from 21mm to 60mm.
- UV Protection: Provides significant reduction of UV rays, protecting interior furnishings from fading.
